| Spændingsforsyning | 230 Vac |
|---|---|
| Maximal power consumption | 750 W |
| Integrated radio receiver | ✔ Somfy RTS, 433.42 MHz |
| Number of remote transmitters possible to memorize | 32 |
| Till. omgivelsestemperatur | -20°C ÷ +60°C |
| Beskyttelsesklasse | IP20 |
| Dimensions | 158 × 262 × 61 mm |
| Integral light | ✔ 230 V, max. 25 W, E14 |
| Inputs for safety devices | - Wired safety edge (optical or resistive) - Safety break - Photocells |
| Safety devices test input | ✔ For photocells |
| Wired control input | ✔ Potential-free contact NO |
| Output for flashing light | - Orange LED, 24 V, max. 4 W |
| Output for alarm sounder | ✔ |
| Voltage of external accessories | 24 Vdc, maximal 150 mA |
| Integrated control buttons | ✔ On front cover: ▲ Up - ■ Stop - ▼ Down |
| Available motor control modes | - Sequential - Semiautomatic - Dedicated (Open/Stop/Close) |
| Automatic closing of the gate | Programmable delay of closing, from 5 to 120 seconds and fast closing after photocells. |
| Diagnosing |
