| Spændingsforsyning | 230 V~ ( +6% -10%) - 50 Hz |
|---|---|
| Absorbed power | 10 W |
| Motor max. load | 800 W |
| Accessories max. load | 0,5 A |
| Electric lock max. load | 15 VA |
| Till. omgivelsestemperatur | -20°C ÷ +55°C |
| Protection fuses | 2 |
| Function logics | Semi-automatic Automatic Safety devices "Stepped" semi-automatic "Stepped" automatic "Stepped" Safety devices Semi-automatic B Dead-man C |
| Opening/closing time | Programmable (from 0 to 120 s) |
| Pause time | Programmable (from 0 to 4 min.) |
| Closing leaf delay | Programmable (from 0 to 4 min.) |
| Opening leaf delay | 2 s (can be excluded) |
| Thrust force | Adjustable on 50 levels for each motor |
| Terminal board inputs | Open Open free leaf Stop Limit-switch Opening safety devices Closing safety devices Power supply + Earth |
| Terminal board outputs | Flashing lamp Motors 24 Vdc accessories power supply 24 Vdc indicator-light Fail safe 12 Vac electric lock power supply |
| Programmable functions | Logic Pause time Thrust Force Torque at initial thrust Opening and closing leaf delay Reversing stroke Over-pushing stroke indicator light Pre-flashing Electric lock Fail safe Safety devices logic |
| Learning function | Simple or complete work time learning, with or without Limit-switch and/or Gatecoder. |
